10-24 H3 3FL SP PT PL-S/O
Item #: YG41M4323
Brand: YG-1 Cutting Tools
Model #: M4323
| Product Specifications | |
|---|---|
| Thread Standard | UNC |
| Connection Diameter Machine Side (DCONMS) | 0.194″ |
| Thread Size | #10 - 24 |
| Thread Cutting Part Length (THL) | 0.531″ |
| Thread Diameter Size (TDZ) | #10 |
| Flute Helix Angle (FHA) | 0 Degrees |
| Threads per Inch (TPI) | 24 |
| Tapping Prehole Diameter (Pre-hole) | 0.152″ |
| Thread Tolerance Class (TCTR) | H3 |
| End Shape | Plug |
| Usable Length (LU) | 0.906″ |
| Shank Type | Square |
| Overall Length (OAL) | 2.38″ |
| Coolant Supply Property (CSP) | No |
| Chamfer | 4P-5P |
| Length Group | 3xD |
| Coating | Steam Oxide |
| Square Size | 0.152″ |
| Flute Count (NOF) | 3 |
| Measurement Type | Inch |
| Cutting Edge Material | P-HSS |
| Series/List # | M4 |
| Tool Type | Spiral Point Tap |
