5/8-11 H3 3FL SPPT PL-S/O
Item #: YG41I0663
Brand: YG-1 Cutting Tools
Model #: I0663
| Product Specifications | |
|---|---|
| Thread Standard | UNF |
| Tool Type | Spiral Point Tap |
| Thread Size | 5/8″ - 18 |
| Connection Diameter Machine Side (DCONMS) | 0.48″ |
| Thread Diameter Size (TDZ) | 5/8″ |
| Thread Cutting Part Length (THL) | 1.083″ |
| Threads per Inch (TPI) | 18 |
| Tapping Prehole Diameter (Pre-hole) | 0.574″ |
| Thread Tolerance Class (TCTR) | H3 |
| End Shape | Plug |
| Usable Length (LU) | 1.811″ |
| Shank Type | Square |
| Overall Length (OAL) | 3.81″ |
| Length Group | 3xD |
| Chamfer | 4P-5P |
| Square Size | 0.36″ |
| Coating | Steam Oxide |
| Measurement Type | Inch |
| Flute Count (NOF) | 3 |
| Series/List # | I0 |
| Cutting Edge Material | HSSE-V3 |
