10 × 10 × 15 × 75 mm 2 Flute 1mm C/R Carbide End Mill-Plain Shank
Item #: YG34SEME6110010
Brand: YG-1 Cutting Tools
Model #: SEME6110010
| Product Specifications | |
|---|---|
| Cutting Diameter (DC) | 10 mm |
| Shank Type | Plain |
| Connection Diameter Machine Side (DCONMS) | 10 mm |
| End Shape | Corner Radius |
| Depth of Cut Maximum (APMX) | 30 mm |
| Usable Length (LU) | 15 mm |
| Overall Length (OAL) | 75 mm |
| Corner Radius (RE) | 1 mm |
| Cutting Edge Material | Carbide |
| Length Group | Long |
| Flute Count (NOF) | 2 |
| Decimal Equivalent | 0.3937″ |
| Flute Helix Angle (FHA) | 30 Degrees |
| Measurement Type | Metric |
