3 × 6 × 4.5 × 70 mm 2 Flute 1mm C/R Carbide End Mill-Plain Shank
Item #: YG34E610301030
Brand: YG-1 Cutting Tools
Model #: SEME610301030
| Product Specifications | |
|---|---|
| Cutting Diameter (DC) | 3 mm |
| Shank Type | Plain |
| Connection Diameter Machine Side (DCONMS) | 6 mm |
| End Shape | Corner Radius |
| Depth of Cut Maximum (APMX) | 30 mm |
| Usable Length (LU) | 4-1/2 mm |
| Overall Length (OAL) | 70 mm |
| Corner Radius (RE) | 1 mm |
| Cutting Edge Material | Carbide |
| Length Group | Long |
| Flute Count (NOF) | 2 |
| Decimal Equivalent | 0.1181″ |
| Flute Helix Angle (FHA) | 30 Degrees |
| Measurement Type | Metric |
