Brand: Widia / Part #: 2836473
Item #: 97595342
Brand: Widia
Model #: 2836473
Product Specifications
| Boring Bar Type | Micro Boring |
| Cutting Direction | Right Hand |
| Minimum Bore Diameter (Decimal Inch) | 0.1560 |
| Material | Solid Carbide |
| Material Grade | Fine Grain |
| Shank Diameter (Decimal Inch) | 5/32 |
| Finish Coating | Bright/Uncoated |
| Manufacturer Grade | CM1 |
| Series | APD |
| Coating Process | Uncoated |
| Maximum Bore Depth (Inch) | 1/2 |
| Maximum Depth of Cut (mm) | 0.05 |
| Overall Length (Decimal Inch) | 1.1500 |
| Primary Workpiece Material | Non-Ferrous Metal; Stainless Steel; Cast Iron; Steel |
| Relief Angle | -3.000 |
| Secondary Workpiece Material | Non-Ferrous Metal; Stainless Steel; Cast Iron; Steel |
