1″ Dia. × 1″ Shank × 2″ DOC × 4-1/2″ OAL, HSSCo TiCN, Coarse , 5 Flute, CW|30° Helix, Weldon, External , Ballnose End Mill
Item #: WK402655069
Brand: Widia
Model #: 2655069
| Product Specifications | |
|---|---|
| Cutting Diameter (DC) | 1″ |
| Shank Type | Weldon |
| Connection Diameter Machine Side (DCONMS) | 1″ |
| Usable Length (LU) | 2″ |
| Depth of Cut Maximum (APMX) | 2″ |
| End Shape | Chamfer |
| Overall Length (OAL) | 4-1/2″ |
| Flute Type | Coarse |
| Cutting Edge Material | HSSCo |
| Coolant Supply Property (CSP) | External |
| Coating | TiCN |
| Chamfer | 0.02″ |
| Flute Count (NOF) | 5 |
| Style | 82-02 SEM Side and Center |
| Flute Helix Angle (FHA) | CW|30 Degrees |
| Decimal Equivalent | 1″ |
