Brand: Ingersoll Cutting Tools / Part #: 3029649
Item #: 96773726
Brand: Ingersoll Cutting Tools
Model #: 3029649
Product Specifications
| Mill Diameter (Decimal Inch) | 0.3125 |
| Program Radius (Decimal Inch) | 0.0510 |
| Number of Flutes | 4 |
| Material | Solid Carbide |
| Finish/Coating | TiAlN |
| Length of Cut (Decimal Inch) | 0.0160 |
| Length of Cut (Inch) | 0.0160 |
| Shank Diameter (Inch) | 5/16 |
| Overall Length (Inch) | 2-1/2 |
| Flute Type | Straight |
| Cutting Direction | Right Hand |
| Helix Angle | 0.00 |
| Reach Length (Decimal Inch) | 1.0000 |
| Neck Diameter (Decimal Inch) | 0.2930 |
| Material Grade | IN2006 |
| Single or Double End | Single |
| Length Type | Long |
| Centercutting | Yes |
| Flute Direction | Right Hand |
| Extended Reach | Yes |
| Shank Type | Cylindrical |
| Series | 47A_RA |
| Chipbreaker | No |
