1/2″ Dia. × 1/2″ Shank × 0.500″ DOC × 4-3/8″ OAL, Carbide DURO, 4 Flute, Shrink Fit, Ballnose End Mill
Item #: TP4684300523
Brand: OSG USA, Inc.
Model #: 84300523
| Product Specifications | |
|---|---|
| Cutting Diameter (DC) | 1/2″ |
| Neck Diameter (DN) | 1/2″ |
| Connection Diameter Machine Side (DCONMS) | 1/2″ |
| Neck Length (LN) | 1/2″ |
| Depth of Cut Maximum (APMX) | 1/2″ |
| Tool Type | Center Cut |
| Overall Length (OAL) | 4-3/8″ |
| End Shape | Ball Nose |
| Cutting Edge Material | Carbide |
| Shank Standard | h6 |
| Coating | DURO |
| Decimal Equivalent | 0.5″ |
| Flute Count (NOF) | 4 |
| Measurement Type | Inch |
| Shank Type | Shrink Fit |
| Series/List # | 8430 |
| Corner Radius (RE) | 1/4″ |
