VFX160L1.05R20E06S10 AH750
Item #: TG436848181
Brand: Tungaloy
Model #: 6848181
| Product Specifications | |
|---|---|
| Application | | Face Milling | High Feed Milling | Profile Milling | |
| Grade | AH750 |
| Cutting Diameter (DC) | 16 mm |
| Coating | TiAlN |
| Applicable Material | | Hard Materials | |
| Tool Cutting Edge Angle (KAPR) | 97 Degrees |
| Flute Count (NOF) | 6 |
| Measurement Type | Metric |
| Corner Radius (RE) | 1 mm |
| fz(max) | 0.65 mm/tooth |
| Cutting Diameter Maximum (DCX) | 16 mm |
| Cutting Edge Material | Carbide |
| Depth of Cut Maximum (APMX) | 1.05 mm |
| Tool Type | Solid dovetail endmills |
| Functional Length (LF) | 16 mm |
| Body Material | Carbide |
| Flute Helix Angle (FHA) | 20 Degrees |
