Emuge - M10x1.50 Metric 6HX 4 Flute TiN Finish PM Cobalt Spiral Point Tap
Item #: 96374152
Brand: Emuge
Model #: B1088F01.0100
Features and Benefits
Plug chamfers are the most commonly used chamfer and are designed for efficiently threading through and blind holes. They have 3 to 5 threads.
Titanium Nitride (TiN) is a multi-purpose coating which increases chip flow in softer materials. The heat and hardness resistance allows the tool to run at higher speeds than uncoated tools.
| Product Specifications | |
|---|---|
| Thread Size (mm) | M10x1.50 |
| Number of Flutes | 4 |
| Chamfer | Plug |
| Class of Fit | 6HX |
| Thread Limit | D5 |
| Finish/Coating | TiN |
| Material | PM Cobalt |
| Through Coolant | Through Coolant |
| Thread Direction | Right Hand |
| Overall Length (mm) | 100.00 |
| Oversize | No |
| Thread Standard | Metric ;M |
| Neck Length (Decimal Inch) | 1.5354 |
| Neck Length (Inch) | 1.5354 |
| Tapping Depth (mm) | 30.00 |
| Shank Diameter (mm) | 10.00 |
| Square Size (mm) | 8.00 |
| Material Application | Stainless Steel |
| Material Application2 | Steel |
