Emuge - 3/8-16 UNC 2BX 3 Flute TiN Finish PM Cobalt Spiral Point Tap
Item #: 96374392
Brand: Emuge
Model #: BU088F01.5011
Features and Benefits
Plug chamfers are the most commonly used chamfer and are designed for efficiently threading through and blind holes. They have 3 to 5 threads.
Titanium Nitride (TiN) is a multi-purpose coating which increases chip flow in softer materials. The heat and hardness resistance allows the tool to run at higher speeds than uncoated tools.
| Product Specifications | |
|---|---|
| Thread Size (Inch) | 3/8-16 |
| Number of Flutes | 3 |
| Chamfer | Plug |
| Class of Fit | 2BX |
| Thread Limit | H5 |
| Finish/Coating | TiN |
| Material | PM Cobalt |
| Through Coolant | Through Coolant |
| Thread Direction | Right Hand |
| Overall Length (Decimal Inch) | 3.9370 |
| Overall Length (mm) | 100.00 |
| Oversize | No |
| Thread Standard | UNC |
| Neck Length (Decimal Inch) | 1.5354 |
| Neck Length (Inch) | 1.5354 |
| Tapping Depth (Inch) | 1-1/8 |
| Shank Diameter (Decimal Inch) | 0.3810 |
| Square Size (Decimal Inch) | 0.2860 |
| Material Application | Stainless Steel |
| Material Application2 | Steel |
