Cleveland - Spiral Point Taps Thread Size (Inch): 7/8-14 Number of Flutes: 4
Item #: 18100321
Brand: Cleveland
Model #: C86131
Features and Benefits
Plug chamfers are the most commonly used chamfer and are designed for efficiently threading through and blind holes. They have 3 to 5 threads.
Titanium Aluminum Nitride (TiAlN) has a higher hardness and oxidation temperature versus TiN and TiCN. As a result, it is particularly advantageous for higher speed operations in a variety of steel machining applications.
Vanadium high speed steel (HSSE) is made of HSS, carbon, vanadium carbide and other alloys to increase abrasive wear resistance and toughness. It is commonly used in general applications on stainless steels and high silicon aluminums.
Product Specifications
Spiral Point Taps; Thread Size (Inch): 7/8-14 ; Number of Flutes: 4 ; Chamfer: Plug ; Class of Fit: 2B ; Finish/Coating: TiAlN ; Material: HSS-E
| Thread Size (Inch) | 7/8-14 |
| Number of Flutes | 4 |
| Chamfer | Plug |
| Class of Fit | 2B |
| Finish/Coating | TiAlN |
| Material | HSS-E |
| Through Coolant | NonThrough Coolant |
| Thread Direction | Right Hand |
| Overall Length (Decimal Inch) | 5.51180 |
| Oversize | No |
| Thread Standard | UNF |
| Material Grade | M35 |
| Thread Length (Inch) | 2.362 |
| Neck Length (Inch) | 1.102 |
| Style | Spiral Point |
| Shank Diameter (Decimal Inch) | 0.6970 |
| Square Size (Decimal Inch) | 0.7500 |
| Material Application | Low Carbon Steel; Alloyed Steel; Stainless Steel; Cast Iron; Hardened Materials |
| Material Application2 | Low Carbon Steel; Alloyed Steel; Stainless Steel; Cast Iron; Hardened Materials |
| PSC Code | 5133 |
