BT40 x TG75 x 70mm Collet Chuck

Item #: RH2224301R
Manufacturer: Rapidhold
Mfg #: 24301R

Technical Specifications:
*Brand Name: Rapidhold *Collet Style: TG75 *Head Length/Projection: 2.75 *Mount: BT40 *Nose Diameter: 1.97 *Overall Length: 6.14 *Shank Length: 3.38 *Size/Range: .0625 - .7500 *Type: Collet Chuck *Weight: 2.45 lbs

Description:
*Produced according to AT3 specifications *Tools are made of a high quality alloy steel *Collet seat taper T.I.R. greater than 0.0002" *Through the spindle coolant capability *Dynamically balanced to G6.5 @ 15,000 RPM *All collet chucks are supplied with depth set screws *All balanced tools are supplied with QA certificate

Shipping Info:
*Actual Weight - 2.4500
