9/64″ Dia. × 11 mm Shank Dia. × 116 mm OAL, 140 Degrees, 40xD, 2 Flutes, Aqua Revo D, Solid Carbide Drills
Item #: AC881519580
Brand: Nachi America Inc
Model #: 1519580
| Product Specifications | |
|---|---|
| Drill Bit Size / Cutting Diameter (DC) | | 9/64″ | |
| Point Angle (SIG) | 140 Degrees |
| Drill Bit Size / Cutting Diameter (DC) - Inch | 9/64″ |
| Functional Length (LF) | 48 mm |
| Decimal Equivalent | 0.1406″ |
| Tool Type | Drill |
| Length Group | 40xD |
| Usable Length (LU) | 50 mm |
| Coating | Aqua Revo D |
| Overall Length (OAL) | 116 mm |
| Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | Aluminum / Non-Ferrous Materials | |
| Flute Count (NOF) | 2 |
| Connection Diameter Machine Side (DCONMS) | 11 mm |
| Cutting Direction (HAND) | Right Hand |
