9/32″ Dia. × 8 mm Shank Dia. × 142 mm OAL, 140 Degrees, 8xD, 2 Flutes, Aqua Revo D, Solid Carbide Drills
Item #: AC861571309
Brand: Nachi America Inc
Model #: 1571309
| Product Specifications | |
|---|---|
| Drill Bit Size / Cutting Diameter (DC) | | 9/32″ | |
| Point Angle (SIG) | 140 Degrees |
| Drill Bit Size / Cutting Diameter (DC) - Inch | 9/32″ |
| Functional Length (LF) | 84 mm |
| Decimal Equivalent | 0.2813″ |
| Tool Type | Drill |
| Length Group | 8xD |
| Usable Length (LU) | 86 mm |
| Coating | Aqua Revo D |
| Overall Length (OAL) | 142 mm |
| Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | Aluminum / Non-Ferrous Materials | |
| Flute Count (NOF) | 2 |
| Connection Diameter Machine Side (DCONMS) | 8 mm |
| Cutting Direction (HAND) | Right Hand |
