VF2SBD5/16 CARBIDE ENDMILL
Item #: MB03613827
Brand: Mitsubishi Materials USA
Model #: 613827
| Product Specifications | |
|---|---|
| Cutting Diameter (DC) | 5/16″ |
| End Shape | Ball |
| Connection Diameter Machine Side (DCONMS) | 0.313″ |
| Corner Radius (RE) | 0.1563″ |
| Depth of Cut Maximum (APMX) | 5/8″ |
| Peripheral Effective Cutting Edge Count (ZEFP) | 2 |
| Overall Length (OAL) | 4″ |
| Length Group | Short |
| Coating | VF |
| Decimal Equivalent | 0.3125″ |
| Flute Count (NOF) | 2 |
| Measurement Type | Inch |
| Flute Helix Angle (FHA) | 30 Degrees |
| Series/List # | VF2SB_INCH |
