MFE0953X02S100 DP1020 3/8″ Dia. × 0.394″ Shank × 1.579″ Flute Length × 3.311″ OAL, 180°, 2 Flute, External Coolant, Solid Carbide Drill
Item #: MB0310562659
Brand: Mitsubishi Materials USA
Model #: 10562659
Product Specifications | |
---|---|
Drill Bit Size / Cutting Diameter (DC) | 3/8″ |
Cutting Edge Material | Carbide |
Drill Bit Size / Cutting Diameter (DC) - Inch | 3/8″ |
Grade | DP1020 |
Decimal Equivalent | 0.375″ |
Measurement Type | Inch |
Length Group | 2xD |
Series/List # | MFE_INCH |
Applicable Material | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | Aluminum / Non-Ferrous Materials |
Usable Length (LU) | 3/4″ |
Connection Diameter Machine Side (DCONMS) | 0.394″ |
Length Chip Flute (LCF) | 1.579″ |
Head Length (LH) | 1.705″ |
Overall Length (OAL) | 3.311″ |
Coolant Supply Property (CSP) | External |
Flute Count (NOF) | 2 |
Point Angle (SIG) | 180 Degrees |
Feature | High efficiency drilling in various types of machining. |
Flute Helix Angle (FHA) | 20 Degrees |
