AOMT184850PEER-H MP6130 INSERT
Item #: MB02800517
Brand: Mitsubishi Materials USA
Model #: 800517
| Product Specifications | |
|---|---|
| Applicable Material | Steel |
| Clearance Angle Major (AN) | 15 Degrees |
| Cutting Edge Length (L) | 18 mm |
| Series/List # | MP6130 |
| Corner Radius (RE) | 5 mm |
| Hole Diameter | 4.7 mm |
| Insert Width (W1) | 9 mm |
| Cutting Edge Material | Carbide |
| Insert Thickness (S) | 4.8 mm |
| Tool Type | rotating_inserts |
| Grade | MP6130 |
| Cutting Edge Effective Length (LE) | 15.9 mm |
| Insert Style | AOMT |
| Measurement Type | Metric |
