JDMW120420ZDSRFTVP15TF
Item #: MB02229163
Brand: Mitsubishi Materials USA
Model #: 229163
| Product Specifications | |
|---|---|
| Applicable Material | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium |
| Clearance Angle Major (AN) | 15 Degrees |
| Corner Radius (RE) | 2 mm |
| Series/List # | VP15TF |
| Inscribed Circle Diameter (IC) | 12 mm |
| Hole Diameter | 4.7 mm |
| Insert Thickness (S) | 4.76 mm |
| Cutting Edge Material | Carbide |
| Wiper Edge Length (BS) | 2.5 mm |
| Tool Type | rotating_inserts |
| Grade | VP15TF |
| Measurement Type | Metric |
| Insert Style | JDMW |
