TKF 12R200AS KPD001 Grade PCD, Indexable Grooving Insert
Item #: KY99TBR16042
Brand: Kyocera Precision Tools
Model #: TBR16042
| Product Specifications | |
|---|---|
| Cutting Width (CW) | 2 mm |
| Number of Cutting Edges | 1 |
| Corner Radius (RE) | 0.1 mm |
| Chip Breaker Type | AS |
| Cutting Depth Maximum (CDX) | 5 mm |
| Insert Style | TKF |
| Insert Thickness (S) | 8.7 mm |
| Number of Teeth | 1 |
| Fixing Hole Diameter (D1) | 5 mm |
| Mounting Style | Screw |
| Grade | KPD001 |
| Series/List # | KTKF |
| Cutting Edge Material | PCD |
| Coating Process | Uncoated |
| Application | Small Parts Machining | Traversing |
| Measurement Type | Metric |
| Applicable Material | Aluminum / Non-Ferrous Materials | Super-Alloys / Titanium |
| Cutting Edge Length (L) | 5.3 mm |
| Cutting Direction (HAND) | Right Hand |
| Insert Width (W1) | 3 mm |
