LOGU 2216PAERGM PR1535 Grade PVD Carbide, Indexable Milling Insert
Item #: KY90TLC40001
Brand: Kyocera Precision Tools
Model #: TLC40001
| Product Specifications | |
|---|---|
| Applicable Material | Steel | Cast Iron | Super-Alloys / Titanium |
| Insert Size | 2216 |
| Application | Facing | Helical Milling | High Feed | Plunging | Pocketing | Ramping | Shouldering | Slotting |
| Corner Chamfer Width (CHW) | 0.0591″ |
| Insert Length (INSL) | 0.8976″ |
| Cutting Direction (HAND) | Right Hand |
| Insert Width (W1) | 0.4921″ |
| Chip Breaker Type | ER-GM |
| Insert Thickness (S) | 0.665″ |
| Series/List # | MFLN |
| Wiper Edge Length (BS) | 0.248″ |
| Hole Diameter | 0.2677″ |
| Insert Included Angle (EPSR) | 90 Degrees |
| Cutting Edge Material | Carbide |
| Coating | MEGACOAT NANO |
| Coating Process | PVD |
| Grade | PR1535 |
| Number of Cutting Edges | 4 |
| Shape | Rectangle |
| Measurement Type | Inch |
| Insert Style | LOGU |
