Brand: Widia / Part #: 2957585
Item #: 95112348
Brand: Widia
Model #: 2957585
Product Specifications
| Insert Style | HPGT |
| Insert Size Code | 06T3 |
| Insert Size | 22 |
| Insert Material | Carbide |
| Manufacturer Grade | TN6520 |
| Thickness (Inch) | 5/32 |
| Inscribed Circle (Decimal Inch) | 0.4291 |
| Corner Radius (Decimal Inch) | 0.0386 |
| Insert Hand | Right Hand |
| Relief Angle | 11.000 |
| Series | M640 |
| Coating Process | PVD |
| Hole Diameter (Decimal Inch) | 0.1732 |
| Maximum Depth of Cut (Decimal Inch) | 0.2146 |
| Number Of Cutting Edges | 6 |
| Insert Shape | Hexagon |
| Rake | Positive |
| Primary Workpiece Material | Cast Iron |
| Primary Workpiece Material Code | K |
| Ansi Code | HPGT225DZERLD |
| Iso Code | HPGT06T3DZERLD |
| Manufacturers Catalog Number | HPGT225DZERLD |
| Cutter Series Compatibility | M640 HP06T3 IN |
| Chip Breaker | LD |
| Cutting Direction | Right Hand |
| Material Application | High-Temperature Alloy; Stainless Steel; Steel |
| Shape | Hexagon |
| Insert Holding Method | Screw |
| Coating Classification | PVD |
| Single or Double Sided Insert | Single |
| Coating/Finish | TiAlN |
| Included Angle Degree | 120 |
| Width (Decimal Inch - 4 Decimals) | 0.4291 |
| Thickness (Decimal Inch - 4 Decimals) | 0.1571 |
| Multi-Use Tool | Yes |
| Length (Decimal Inch - 4 Decimals) | 0.4291 |
