DORMER - 9mm Carbide-Tipped 6 Flute Chucking Reamer
Item #: 65643660
Brand: DORMER
Model #: 0144268
Features and Benefits
Carbide tips cuts faster than high speed steel. It is commonly used on ferrous and nonferrous metals including cast iron, steel and steel alloy.
Spiral flute reamers are used in blind and through-hole operations. They are used to bridge interrupted cuts.
| Product Specifications | |
|---|---|
| Reamer Diameter (mm) | 9.00 |
| Reamer Diameter (Decimal Inch) | 0.3546 |
| Reamer Material | Carbide-Tipped |
| Shank Type | Straight |
| Flute Type | Spiral |
| Overall Length (mm) | 125.00 |
| Overall Length (Decimal Inch) | 4.9250 |
| Flute Length (mm) | 36.00 |
| Flute Length (Decimal Inch) | 1.4184 |
| Variable Diameter Reamer Type | None |
| Number of Flutes | 6 |
| Maximum Shank Diameter (mm) | 9.00 |
| Maximum Shank Diameter (Decimal Inch) | 0.3546 |
| Over/Under Size Reamer | No |
| Dowel Pin Reamer | No |
| Spiral Direction | Left Hand |
| Cutting Direction | Right Hand |
| Reamer Finish/Coating | Bright |
| Reamer Diameter Tolerance (mm) | +0.015 to 0.000 |
