16IR 8ACME PT AC50C
Item #: FG322411843
Brand: Tool-Flo
Model #: 2411843
| Product Specifications | |
|---|---|
| Thread Standard | ACME |
| Insert Style | Laydown (LT) |
| Inscribed Circle Diameter (IC) | 3/8″ |
| Cutting Direction (HAND) | Right Hand |
| Insert Length (INSL) | 0.63″ |
| Shape | 60° Triangle |
| Threads per Inch (TPI) | 8 Threads/" |
| Threads per Inch Minimum (TPIN) | 8 Threads/" |
| Insert Thickness (S) | 0.252″ |
| Threads per Inch Maximum (TPIX) | 8 Threads/" |
| Cutting Width (CW) | 0.041″ |
| Tool Type | Threading Regular Inserts |
| Grade | AC50C AlTiN |
| Measurement Type | Inch |
| Application | | Int Threading Laydown | |
| Body Material | Carbide |
