Arno - 1.024" Max Depth, 0.079 to 2.047" Width, External Left Hand Indexable Grooving/Cutoff Toolholder
Item #: 11428786
Brand: Arno
Model #: 89550
| Product Specifications | |
|---|---|
| Internal or External | External |
| Hand of Holder | Left Hand |
| Maximum Depth of Cut (mm) | 26.00 |
| Maximum Depth of Cut (Decimal Inch) | 1.0240 |
| Minimum Groove Width (Decimal Inch) | 0.0790 |
| Minimum Groove Width (mm) | 2.01 |
| Maximum Groove Width (Decimal Inch) | 2.0470 |
| Overall Length (Decimal Inch) | 5.9060 |
| Series | SA Parting / Grooving |
| Toolholder Style | HSA Monoblock |
| Insert Compatibility | SA 35-20 |
| Shank Height (mm) | 25.00 |
| Shank Width/Diameter (Decimal Inch) | 0.9840 |
| Through Coolant | NonThrough Coolant |
| Insert Holding Method | Screw |
| Head Length (Decimal Inch) | 1.0240 |
| Manufacturers Catalog Number | HSA 2525L-SA3502-52 |
