ING2M100RCB IC807
Item #: EH6411936
Brand: Iscar
Model #: 6411936
| Product Specifications | |
|---|---|
| Cutting Width (CW) | 0.039″ |
| Application | | Ext. Grooving | Groove Turn & Parting Inserts | Int. Grooving | |
| Corner Radius (RE) | 0.0075″ |
| Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Hi Temp Alloys | |
| Insert Thickness (S) | 0.219″ |
| Max. Grooving Feed (fg(max)) | 0.0024 ″/rev |
| Insert Length (INSL) | 0.51″ |
| Min. Grooving Feed (fg(min)) | 0.0016 ″/rev |
| Cutting Depth Maximum (CDX) | 0.05″ |
| Tool Type | Groove-Turn Precision Inserts |
| Cutting Edge Material | Carbide |
| Measurement Type | Inch |
| Coating | TiAlN+TiN |
| Body Material | Carbide |
| Grade | IC807 |
