APKT 1003PDR-HM-CS IC830
Item #: EH563321498
Brand: Iscar
Model #: 3321498
| Product Specifications | |
|---|---|
| Applicable Material | | Steel | Stainless Steel | Hi Temp Alloys | |
| Grade | IC830 |
| Application | | Countersinking | Drill Mill | Facing | Milling Inserts | Plunging & Recessing | Rampdown | Shouldering | Slanted Shoulder & Chamfer | Slotting | |
| Maximum Feed per Tooth (fz(max)) | 0.0059 ″/tooth |
| Cutting Edge Length (L) | 0.431″ |
| Cutting Edge Material | Carbide |
| Insert Length (INSL) | 0.431″ |
| Tool Type | Single sided Inserts |
| Corner Radius (RE) | 0.0315″ |
| Minimum Feed per Tooth (fz(min)) | 0.0031 ″/tooth |
| Depth of Cut Maximum (APMX) | 0.315″ |
| Number of Cutting Edges | 2 |
| Insert Width (W1) | 0.264″ |
| Cutting Edge Effective Length (LE) | 0.396″ |
| Insert Thickness (S) | 0.14″ |
| Measurement Type | Inch |
| Wiper Edge Length (BS) | 0.047″ |
| Body Material | Carbide |
| Coating | AlTiN+TiN |
