‎DC 1″ x DCONMS 1″ x APMX 1-1/2″ x OAL 7″

‎DC 1″ x DCONMS 1″ x APMX 1-1/2″ x OAL 7″


Item #: CW8059020
Brand: Precision Cutting Tools
Model #: 9584336

Product Specifications
Cutting Diameter (DC) 1″
Grade H5003 Vulcan
Connection Diameter Machine Side (DCONMS) 1″
Neck Diameter (DN) 0.97
Depth of Cut Maximum (APMX) ‎1-1/2″
Peripheral Effective Cutting Edge Count (ZEFP) 5
Overall Length (OAL) 7″
Tool Type Solid Carbide Endmill
Cutting Edge Material Carbide
Length Group Long - Necked
Coating VARIANTIC
Coolant Supply Property (CSP) External
Flute Count (NOF) 5
Shank Standard h6
Flute Helix Angle (FHA) 38 Degrees
Body Material Carbide
Shank Type Round
Style Necked
End Shape Corner Radius
Decimal Equivalent 1″
Usable Length (LU) 5″
Measurement Type Inch
Applicable Material | Cast Iron | Hard Materials | Hi Temp Alloys | Stainless Steel | Steel |
Series/List # 577
Application Finishing | HEM | Semi Finishing | Slotting
Shank Size (SS) 1″
Corner Radius (RE) 1/8″
$778.97
