1/2″ Dia. × 1/2″ Shank × 7/8″ DOC × 5″ OAL, Exxtral Carbon (DLC), 3 Flute, Variable Helix, Straight, External, Square, Solid End Mill
Item #: CW8058384
Brand: Precision Cutting Tools
Model #: 9525241
| Product Specifications | |
|---|---|
| Cutting Diameter (DC) | 1/2″ |
| Neck Diameter (DN) | 0.48″ |
| Connection Diameter Machine Side (DCONMS) | 1/2″ |
| Peripheral Effective Cutting Edge Count (ZEFP) | 3 |
| Depth of Cut Maximum (APMX) | 7/8″ |
| Tool Type | Solid Carbide Endmill |
| Overall Length (OAL) | 5″ |
| Maximum Feed per Tooth (fz(max)) | 0.007″ |
| Coating | Exxtral Carbon (DLC) |
| Minimum Feed per Tooth (fz(min)) | 0.002″ |
| Flute Count (NOF) | 3 |
| Length Group | Long - Necked |
| Flute Helix Angle (FHA) | Variable |
| Coolant Supply Property (CSP) | External |
| Shank Type | Cylindrical |
| Shank Standard | h6 |
| End Shape | Square |
| Body Material | Carbide |
| Usable Length (LU) | 3-1/8″ |
| Style | Necked |
| Applicable Material | Aluminum / Non-Ferrous Materials |
| Decimal Equivalent | 0.5″ |
| Application | Slotting | Roughing | HEM | Semi-Finish | Finish |
| Measurement Type | Inch |
| Corner Radius (RE) | 0″ |
| Series/List # | 360 |
| Grade | A5005 |
| Shank Size (SS) | 1/2″ |
