Combination Chamfer & Countersink Drills; Maximum Drill Diameter (Decimal Inch): 10.40 mm; Maximum Drill Diameter (mm): 10.40 mm; Minimum Drill Diameter (mm): 10.00 mm; Shank Type: Weldon Flat; Body Shank Diameter (mm): 16.00 mm; Chuck Shank Diameter (mm)
Item #: 97850341
Brand: Ingersoll Cutting Tools
Model #: 3204517
Product Specifications
| Maximum Drill Diameter (Decimal Inch) | 10.40 mm |
| Maximum Drill Diameter (mm) | 10.40 mm |
| Minimum Drill Diameter (mm) | 10.00 mm |
| Shank Type | Weldon Flat |
| Body Shank Diameter (mm) | 16.00 mm |
| Chuck Shank Diameter (mm) | 16.00 mm |
| Drill Shank Diameter (Decimal Inch) | 10.40 mm |
| Compatible Insert Style | TNA; KOMT; TMA; TKA; TPF |
| Number of Drill Inserts | 1 |
| Compatible Insert Size Code | 0501; 1000 |
| Chamfer Angle | 45.000 |
| Coolant Entry Style Code | 1-Axial Concentric Entry |
| Body Diameter (mm) | 0.6690 |
| Overall Length (mm) | 102.11 |
| Overall Length (Decimal Inch) | 102.11 |
| Tool Material | Steel |
| Cutting Direction | Right Hand |
| Coated | Coated |
| Coating | (TiN) |
| Number Of Flutes | 2 |
| Tool Application | Chamfering; Solid Drilling |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Universal |
| Included Angle | 140.00 |
| Insert Holding Method | Screw |
| Shank Length (Decimal Inch) | 48.01 mm |
| Shank Length (mm) | 48.01 mm |
| Through Coolant | Normal Pressure |
| Series | TC |
