Kyocera - TWFGTR200 PR1025 Carbide Grooving Insert
Item #: 92697820
Brand: Kyocera
Model #: 8827730
Product Specifications
| Insert Style | TWFGT |
| Insert Size | 200 |
| Material | Carbide |
| Cutting Width (mm) | 2.00 |
| Cutting Width (Decimal Inch) | 0.0787 |
| Maximum Depth of Cut (mm) | 3.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.1181 |
| Manufacturer's Grade | PR1025 |
| Coating | TiCN |
| Cutting Direction | Right Hand |
| Insert Hand | Right Hand |
| Cutting Height (mm) | 6.40 |
| Cutting Height (Decimal Inch) | 0.2520 |
| Relief Angle | 5 |
| Multi-Use Application | Facing |
| Multi-Use Tool | Yes |
| Corner Radius (mm) | 0.05 |
| Corner Radius (Decimal Inch) | 0.001969 |
| Coating Process | PVD |
| Overall Length (mm) | 16.00 |
| Overall Length (Decimal Inch) | 0.6299 |
| Series | TWFGT |
| Rake Angle | 25 |
| Manufacturers Catalog Number | TWFGTR200 |
| Insert Thickness (Decimal Inch) | 0.0937 |
| Insert Thickness (mm) | 2.3800 |
| Series Number | TWFGT |
| Corner Radius (Inch) | 0.001969 |
