Iscar - External Thread, 0.7874" Max Depth of Cut, 3mm Min Groove Width, 135mm OAL, Right Hand Indexable Grooving Cutoff Toolholder - 32mm Shank Height x 32mm Shank Width, PENTA D Insert Style, PCH Toolholder Style, Series PentaCut
Item #: 91101592
Brand: Iscar
Model #: 2302577
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Internal or External | External |
| Hand of Holder | Right Hand |
| Maximum Depth of Cut (mm) | 20.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.7874 |
| Minimum Groove Width (Decimal Inch) | 0.1180 |
| Minimum Groove Width (mm) | 3.00 |
| Maximum Groove Width (mm) | 3.20 |
| Overall Length (mm) | 135.00 |
| Series | PentaCut |
| Toolholder Style | PCH |
| Insert Compatibility | PENTA D |
| Shank Height (mm) | 32.00 |
| Shank Width/Diameter (mm) | 32.00 |
| Through Coolant | NonThrough Coolant |
| Insert Holding Method | Screw |
| Back of Bar to Cutting Edge (Decimal Inch) | 1.2100 |
| Head Height (mm) | 43.50 |
| Head Length (mm) | 33.30 |
| Shank Length (mm) | 101.70 |
| Complete Insert Compatibility | PENTA D-N-C; PENTA D-R/L-C |
