Open-Center Hydraulic Lathe Cylinders; Material: AC2B; SCM415; Bore Size (mm): 117.50; Piston Diameter: 250.000; Piston Push Force: 138 kN; Piston Pull Force: 126 kN; Thread Size (Metric): M112 x 2.0; Maximum Rpm: 3000.000; Maximum Operating Pressure: 4.0
Item #: 90017047
Brand: Samchully
Model #: SDL-25411CA2
Product Specifications
| Material | AC2B; SCM415 |
| Bore Size (mm) | 117.50 |
| Piston Diameter | 250.000 |
| Piston Push Force | 138 kN |
| Piston Pull Force | 126 kN |
| Thread Size (Metric) | M112 x 2.0 |
| Maximum Rpm | 3000.000 |
| Maximum Operating Pressure | 4.0 kgf/cm? |
| Total Leakage | 6 |
| Overall Width | 24 |
| Overall Height | 24 in |
| Overall Depth | 24 in |
