15PC 135° HS-CO HD Jobber Lgth Drill TiN-Tipped Set
Item #: 81206369
Brand: Cle-Line
Model #: C66114
Product Specifications
| Drill Bit Set Type | Jobber Length Drill Bits |
| Number of Pieces | 15.000 |
| Tool Material | Cobalt |
| Minimum Drill Bit Size (Frac Inch) | 1/16 |
| Maximum Drill Bit Size (Frac Inch) | 1/2 |
| Shank Type | Straight |
| Coating/Finish | Titanium Nitride |
| Point Type | Split Point |
| Drill Point Angle | 135 |
| Number Of Hole Sizes | 15 |
| Series | 1501-TT |
| Drill Bit Sizes Included (Inch) | 1/16;3/32;1/8;5/32;3/16;7/32;1/4;9/32;5/16;11/32;3/8;13/32;7/16;15/32;1/2 |
| Maximum Hole Size | 1/2 |
| Shank Diameter | 5/32; 15/32; 7/16; 13/32; 5/16; 11/32; 3/32; 7/32; 9/32; 1/2; 1/16; 3/16; 1/4; 1/8; 3/8 |
| Overall Length | 5-3/4; 1-7/8; 3-1/8; 2-3/4; 4-1/2; 4-1/4; 4-3/4; 2-1/4; 4; 5; 6; 3-1/2; 5-1/2; 3-3/4; 5-1/4 |
| Contents | 5/32; 15/32; 7/16; 13/32; 5/16; 11/32; 3/32; 7/32; 9/32; metal Case; 1/2; 1/16; 3/16; 1/4; 1/8; 3/8 |
| Coolant Through | No |
| Cutting Direction | Right Hand |
| Drill Length Type | Jobber Length |
| Flute Length | 7/8;1-1/4;1-5/8;2;2-5/16;2-1/2;2-3/4;2-15/16;3-3/16;3-7/16;3-5/8;3-7/8;4-1/16;4-5/16;4-1/2 |
| Material Set Type | Cobalt |
| Specification Designation | ANSI |
| Standards | ANSI |
| UNSPSC Code | 20111614 |
| Storage Unit Material | Metal |
| System Of Measurement | Fractional Inch |
| Tool Application | Metalworking |
| Tool Performance | Heavy Duty |
| Storage Unit Type | Index |
| Country of Origin | VARIOUS |
