US Motors - 1/2 hp, ODP Enclosure, Auto Thermal Protection, 1,725 RPM, 230 Volt, 60 Hz, Industrial Electric AC/DC Motor - Size 56 Frame, Cradle Mount, 2 Speed, Sleeve Bearings, 3.6/2.0 Full Load Amps, B Class Insulation, CW Shaft End
Item #: 87956603
Brand: US Motors
Model #: 7063
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type of Enclosure | ODP |
| Horsepower | 1/2 |
| Thermal Protection Rating | Auto |
| Name Plate RPMs | 1725 |
| Voltage | 230 |
| Frequency Hz | 60 |
| Frame Size | 56 |
| Mount Type | Cradle |
| Number of Speeds | 2 |
| Bearing Type | Sleeve |
| Full Load Amperage | 3.6/2.0 |
| Insulation Class | B |
| Full Load Efficiency Rating | 66.70 |
| Motor Run Capacitor Micro Farid | 0.00 |
| Motor Run Capacitor Volts | 0 |
| Service Factor Rating | 1.00 |
| Motor Rotation | CW Shaft End |
| PSC Code | 6105 |
