Gardner Spring - 1/2" Bolt, 0.505" ID, Grade 17-7 PH Stainless Steel, Belleville Disc Spring - 1" OD, 0.091" High, 0.073" Thick
Item #: 87779393
Brand: Gardner Spring
Model #: MB1000-073-S
Exact Tooling IR#: 04
Features and Benefits
Belleville disc springs, also known as conical washers, have a curved shape that creates a spring-like action. They are used in applications that require heavy loads.
| Product Specifications | |
|---|---|
| Type | Belleville Disc Spring |
| Bolt Size (Inch) | 1/2 |
| System of Measurement | Inch |
| Inside Diameter (Decimal Inch) | 0.5050 |
| Material | Stainless Steel |
| Material Grade | 17-7 PH |
| Outside Diameter (Decimal Inch) | 1.0000 |
| Thickness (Decimal Inch) | 0.0730 |
| Overall Height (Decimal Inch) | 0.0910 |
| Deflection (Decimal Inch) | 0.0090 |
| Deflection to Flat (Decimal Inch) | 0.0090 |
| Minimum Inside Diameter (Decimal Inch) | 0.5050 |
| Load at Flat (Lb.) | 1364.60 |
| Load at Deflection (Lb.) | 697.90 |
