Parlec - 33 Piece, 1/16" to 9/16" Capacity, Double Angle Collet Set - 0.0004" TIR, Increments of 1/64", Series DA100
Item #: 87693313
Brand: Parlec
Model #: DA100-S033
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Collet System | Double Angle |
| Collet Series | DA100 |
| Number of Pieces | 33 |
| Minimum Collet Capacity (Inch) | 1/16 |
| Minimum Collet Capacity (Decimal Inch) | 0.0625 |
| Maximum Collet Capacity (Inch) | 9/16 |
| Maximum Collet Capacity (Decimal Inch) | 0.5625 |
| Size Increments (Inch) | 1/64 |
| Size Increments (Decimal Inch) | 0.0156 |
| TIR (Decimal Inch) | 0.000400 |
| Size 1 (Decimal Inch) | 0.0469-0.0625; 0.0625-0.0781; 0.0781-0.0938; 0.0938-0.1094; 0.1094-0.1250; 0.1250-0.1406; 0.1406-0.1562; 0.1562-0.1719; 0.1719-0.1875; 0.1875-0.2031; 0.2031-0.2188; 0.2188-0.2344; 0.2344-0.2500; 0.2500-0.2656; 0.2656-0.2812; 0.2812-0.2969; 0.2969-0.3125; |
| Size 2 (Decimal Inch) | 0.3594-0.3750; 0.3750-0.3906; 0.3906-0.4062; 0.4062-0.4219; 0.4219-0.4375; 0.4375-0.4531; 0.4531-0.4688; 0.4688-0.4844; 0.4844-0.5000; 0.5000-0.5156; 0.5156-0.5312; 0.5312-0.5469; 0.5469-0.5625 |
| PSC Code | 5136 |
