Starrett - 50 to 65mm, 80mm Gage Depth, Mechanical Inside Micrometer - 0.005mm Graduation, 0.005mm Accuracy, Ratchet Stop Thimble
Item #: 86896438
Brand: Starrett
Model #: 67863
Exact Tooling IR#: 04
Features and Benefits
Ratchet stop thimbles offer audible feedback and constant measuring pressure on the spindle while measuring. They cause micro-shocks and requires two hands to make a measurement.
| Product Specifications | |
|---|---|
| Minimum Measurement (mm) | 50.00 |
| Maximum Measurement (mm) | 65.00 |
| Graduation (mm) | 0.0050 |
| Thimble Type | Ratchet Stop |
| Accuracy (mm) | 0.0050 |
| Gage Depth (mm) | 80.00 |
| Maximum Extension Rod Length (mm) | 152.40 |
| Maximum Extension Rod Length (Inch) | 6 |
| Number of Contact Points | 3 |
| Number of Setting Rings Included | 1 |
| Setting Ring Diameter (mm) | 65.00 |
| Includes | Case; Contacts; Instructions; Setting Ring; Wrenches |
| Digital Counter | No |
