SGS - 3/4", 1" LOC, 3/4" Shank Diam, 6" OAL, 2 Flute, Solid Carbide Square End Mill - Single End, TiB2 Finish, Spiral Flute, 35° Helix, Centercutting, Right Hand Cut, Right Hand Flute, Series 47E
Item #: 86553070
Brand: SGS
Model #: 34685
Exact Tooling IR#: 04
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Titanium diboride (TiB2) is a corrosion resistant ceramic compound made of titanium and boron. It is commonly used on nonferrous materials including aluminum and magnesium alloys.
Center Cutting tools have one or more cutting edges at the tip and are used in a variety of applications including plunging, drilling or ramping.
| Product Specifications | |
|---|---|
| Mill Diameter (Inch) | 3/4 |
| Mill Diameter (Decimal Inch) | 0.7500 |
| Number of Flutes | 2 |
| Length of Cut (Inch) | 1 |
| Length of Cut (Decimal Inch) | 1.0000 |
| Material | Solid Carbide |
| Finish/Coating | TiB2 |
| Shank Diameter (Inch) | 3/4 |
| Single or Double End | Single |
| Overall Length (Inch) | 6 |
| Center Cutting | Center Cutting |
| Flute Direction | Right Hand |
| Cutting Direction | Right Hand |
| Helix Angle | 35.00 |
| Flute Type | Spiral |
| Mill Diameter Tolerance (Decimal Inch) | -0.0001/-0.0004 |
| Reach Length (Inch) | 3-3/8 |
| Chipbreaker | No |
| Extended Reach | Yes |
| Shank Diameter Tolerance (Decimal Inch) | +0.00000/-0.00051 |
| Series/List | 47E |
