US Motors - 1/2 hp, TEAO Enclosure, Manual Thermal Protection, 1,725 RPM, 115/230 Volt, 60 Hz, Industrial Electric AC/DC Motor - Size 48 Frame, Band Mount, 1 Speed, Ball Bearings, 5.0/2.5 Full Load Amps, B Class Insulation, CW Drive End Rev
Item #: 86147220
Brand: US Motors
Model #: FD12AM2P4ZRS
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type of Enclosure | TEAO |
| Horsepower | 1/2 |
| Thermal Protection Rating | Manual |
| Name Plate RPMs | 1725 |
| Voltage | 115/230 |
| Frequency Hz | 60 |
| Frame Size | 48 |
| Mount Type | Band |
| Number of Speeds | 1 |
| Bearing Type | Ball |
| Full Load Amperage | 5.0/2.5 |
| Insulation Class | B |
| Full Load Efficiency Rating | 77.30 |
| Motor Run Capacitor Micro Farid | 12.50 |
| Motor Run Capacitor Volts | 0 |
| Service Factor Rating | 1.00 |
| Motor Rotation | CW Drive End Rev |
| PSC Code | 6105 |
