Kennametal - Straight Shank, Series DA200, Double Angle Reamer Collet Chuck - 1-1/2 Inch Projection, 1/64 to 3/8 Inch Collet Capacity, 3 Inch Shank Length
Item #: 84943315
Brand: Kennametal
Model #: 1015981
Exact Tooling IR#: 04
Features and Benefits
Straight shanks are used for general purpose machining and commonly have a larger diameter than taper shanks.
| Product Specifications | |
|---|---|
| Collet System | Double Angle Reamer |
| Collet Series | DA200 |
| Shank Type | Straight Shank |
| Shank Diameter (Inch) | 1 |
| Projection (Decimal Inch) | 1.5000 |
| Through Coolant | No |
| Minimum Collet Capacity (Inch) | 1/64 |
| Maximum Collet Capacity (Inch) | 3/8 |
| Overall Length (Decimal Inch) | 4.5000 |
| Shank Length (Inch) | 3 |
| Shank Length (Decimal Inch) | 3.0000 |
| Hex Diameter (Inch) | 15/16 |
| Hex Diameter (Decimal Inch) | 0.9375 |
| Float From Center (Decimal Inch) | 0.0040 |
| PSC Code | 5136 |
