Mapal - Shrink-Fit Tool Holders & Adapters Shank Type: Taper Shank Taper Size: CAT40
Item #: 11454030
Brand: Mapal
Model #: 30647427
Features and Benefits
Taper shanks are held in the machine spindle or in a toolholder clamping system.
Product Specifications
Shrink-Fit Tool Holders & Adapters; Shank Type: Taper Shank ; Taper Size: CAT40 ; Hole Diameter (mm): 5.00 ; Projection (mm): 80.00 ; Nose Diameter (mm): 15.00 ; Through Coolant: Through Coolant
| Shank Type | Taper Shank |
| Taper Size | CAT40 |
| Hole Diameter (mm) | 5.00 |
| Projection (mm) | 80.00 |
| Nose Diameter (mm) | 15.00 |
| Through Coolant | Through Coolant |
| Clamping Depth (mm) | 30.00 |
| Overall Length (mm) | 148.25 |
| Balanced to (RPM) | 25000 |
