Reduced Shank Drill Bit: 0.9055'' Dia, 1/2'' Shank Dia, 118 ™, High Speed Steel 158mm OAL, 82mm Flute Length, Bright/Uncoated Finish, Straight-Cylindrical Shank, RH Cut, Series A170
Item #: 80998669
Brand: DORMER
Model #: 5968749
Product Specifications
| Drill Bit Size (mm) | 23.00 |
| Shank Diameter (Decimal Inch) | 0.5000 |
| Tool Material | High Speed Steel |
| Drill Point Angle | 118 |
| Shank Type | Straight-Cylindrical |
| Flute Length (mm) | 82.00 |
| Overall Length (mm) | 158.00 |
| Coating/Finish | Bright/Uncoated |
| Series | A170 |
| Drill Bit Size (Decimal Inch) | 0.9055 |
| Shank Diameter (Decimal Inch) | 1/2 |
| Flute Length (Decimal Inch) | 3.2308 |
| Cutting Direction | Right Hand |
| Flute Type | Spiral |
| Spiral Type | Regular |
| Number Of Flutes | 2 |
| Drill Bit Diameter Tolerance | 0.000 to -0.033 mm |
| Tool Performance | General Purpose |
| Drill Length Type | Reduced Shank |
| Maximum Drilling Depth (Decimal Inch) | 3.2308 |
| Maximum Drilling Depth (mm) | 82.00 |
| Flute Length x Diamter Ratio | 4xD |
| Secondary Workpiece Material | Synthetic; Aluminum; Cermet; Titanium; Nickel; Magnesium; Copper |
| Secondary Workpiece Material Code | P; S; H; K; M; N; O |
| Coolant | No |
