Value Collection - RD16 P Grade TCN55 Carbide Turning Insert - TiN Finish, Round, 1" Inscr Circle, 1/4" Thick
Item #: 78236163
Brand: Value Collection
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | RD |
| Insert Size | 16 |
| Material | Carbide |
| Inscribed Circle (mm) | 25.40 |
| Inscribed Circle (Decimal Inch) | 1.0000 |
| Inscribed Circle (Inch) | 1 |
| Thickness (Inch) | 1/4 |
| Thickness (Decimal Inch) | 0.2500 |
| Manufacturer's Grade | TCN55 |
| Coating | TiN |
| Material Grade | C5 |
| Chip Breaker | P |
| Hole Diameter (Decimal Inch) | 0.2600 |
| Relief Angle | 15 |
| Primary Workpiece Material | P; M |
| Insert Holding Method | Screw |
| Shape | Round |
