Value Collection - M20x2.50 Metric Coarse Hex Socket Drive, Socket Cap Screw - Grade 18-8 & Austenitic A2 Stainless Steel, Black Oxide Finish, Partially Threaded, 60mm Length Under Head
Item #: 78082898
Brand: Value Collection
Exact Tooling IR#: 04
Features and Benefits
Socket cap head types have large cylindrical heads with recessed hex-shaped drives. They are ideal for applications where limited clearance would not allow the use of wrenches and sockets.
Hex socket drive types have a hex-shaped recess in the head and are driven with hex keys or hex socket bits. The driving surface is protected from external damage and provides six sides of contact surface for added torque.
Stainless steel is a strong, corrosion-resistant alloy with excellent resistance to heat. It is used in high-stress, outdoor and corrosive applications.
| Product Specifications | |
|---|---|
| System of Measurement | Metric |
| Head Type | Socket Cap |
| Drive Type | Hex Socket |
| Thread Size (mm) | M20x2.50 |
| Length Measurement Type | Length Under Head |
| Length (mm) | 60.00 |
| Material | Stainless Steel |
| Finish/Coating | Black Oxide |
| Full or Partial Threading | Partially Threaded |
| Thread Standard | Metric Coarse |
| Fastener Standard | DIN 912 |
| Hex Key Size (mm) | 17.00 |
| Material Grade | 18-8; Austenitic Grade A2 |
