Seco - Left Hand Cut, Size C6, DN.. 44 Insert Compatiblity, Internal Modular Turning & Profiling Cutting Unit Head - 26.92mm Ctr to Cutting Edge, 139.95mm Head Length, Series Seco-Capto
Item #: 77892222
Brand: Seco
Model #: 43470
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| System Size | C6 |
| Series Name | Seco-Capto |
| Cutting Direction | Left Hand |
| Head Length/Projection (mm) | 139.95 |
| Head Length/Projection (Decimal Inch) | 5.5100 |
| Insert Style | DN.. 44 |
| Internal or External | Internal |
| Center to Cutting Edge (mm) | 26.92 |
| Center to Cutting Edge (Decimal Inch) | 1.0600 |
| Insert Holding Method | Lever |
| Through Coolant | NonThrough Coolant |
| Axial Rake Angle | -6 |
| Neck Diameter (mm) | 62.99 |
| Neck Diameter (Decimal Inch) | 2.4800 |
| Complete Insert Compatibility | DNGA 441S-00625-L1-U; DNGA 441S-L0-B; DNGA 442E25-L1-U; DNGA 442S-00625-L0-B; DNGA 442S-00625-L1-B; DNGA 442S-00625-L1-U; DNGA 442S-L0-B; DNGA 442S-L1-B; DNGA 443S-00625-L1-B; DNGA 443S-00625-L1-U; DNGA 443S-L1; DNGM 442-MF1; DNGM 442F-MF1; DNMA 442; DNMA |
