Indexable Ball Nose End Mills; Milling Diameter: 1.0000 in; Maximum Depth Of Cut: 1.1000 in; Shank Diameter: 1.0000 in; Shank Type: Cylindrical; Compatible Insert Style: NHET; Compatible Insert Size Code: 2503; Toolholder Style: 15W9X; Series: 15W7V; Over
Item #: 77886604
Brand: Ingersoll Cutting Tools
Model #: 3010580
Product Specifications
| Milling Diameter | 1.0000 in |
| Maximum Depth Of Cut | 1.1000 in |
| Shank Diameter | 1.0000 in |
| Shank Type | Cylindrical |
| Compatible Insert Style | NHET |
| Compatible Insert Size Code | 2503 |
| Toolholder Style | 15W9X |
| Series | 15W7V |
| Overall Length (mm) | 1.00 |
| Overall Length (Decimal Inch) | 1.00 |
| Overall Length (Inch) | 1.00 |
| Tool Application | Chamfering; Profile Milling; Milling |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Universal |
| Insert Holding Method | Screw |
| Toolholder Material | Steel |
| Through Coolant | None |
| Tapered Neck | No |
| Number of Flutes | 1 |
| Head Length (Decimal Inch) | 5.7500 in |
