Seco - RCGS6F 46 Grade 890 Carbide Turning Insert - Uncoated, Round, 1/2" Inscr Circle, 21/32" Thick
Item #: 76696012
Brand: Seco
Model #: 55799
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | RCGS |
| Insert Size | 6F |
| Material | Carbide |
| Inscribed Circle (mm) | 12.70 |
| Inscribed Circle (Decimal Inch) | 0.5000 |
| Inscribed Circle (Inch) | 1/2 |
| Thickness (Inch) | 21/32 |
| Thickness (Decimal Inch) | 0.6563 |
| Manufacturer's Grade | 890 |
| Coating | Uncoated |
| Material Grade | Micrograin |
| Chip Breaker | 46 |
| Relief Angle | 7 |
| Insert Holding Method | Clamp |
| Shape | Round |
