ProMax - 9/16", 1-1/4" LOC, 9/16" Shank Diam, 3-1/2" OAL, 4 Flute, Solid Carbide Square End Mill
Item #: 75943399
Brand: ProMax
Model #: 111-03614
Product Specifications
| Mill Diameter (Inch) | 9/16 |
| Mill Diameter (Decimal Inch) | 0.5625 |
| Number of Flutes | 4 |
| Length of Cut (Inch) | 1-1/4 |
| Length of Cut (Decimal Inch) | 1.2500 |
| Material | Solid Carbide |
| Finish/Coating | AlTiN |
| Shank Diameter (Inch) | 9/16 |
| Single or Double End | Single |
| Overall Length (Inch) | 3-1/2 |
| Center Cutting | Center Cutting |
| Flute Direction | Right Hand |
| Cutting Direction | Right Hand |
| Helix Angle | 40.00 |
| Variable Helix | No |
| Flute Type | Spiral |
| Material Grade | Micrograin |
| Chipbreaker | No |
| Extended Reach | No |
| Series/List | 111 |
