Milling Insert: TPKN 2204PDSR CTPP235, CTPP235, Solid Carbide N/A Finish, 1.0000″ OAW
Item #: 75051656
Brand: Ceratizit
Model #: 51068125
Product Specifications
| Insert Style | TPKN |
| Insert Size Code | 2204 |
| Insert Material | Solid Carbide |
| Width (Inch) | 1 |
| Manufacturer Grade | CTPP235 |
| Inscribed Circle (Decimal Inch) | 0.5000 |
| Insert Hand | Right Hand |
| Relief Angle | 11.00 |
| Series | TPKN |
| Coating Process | PVD |
| Maximum Depth of Cut (Decimal Inch) | 0.6161 |
| Number Of Cutting Edges | 3 |
| Cutting Edge Effective Length (Decimal Inch) | 0.8661 |
| Insert Shape | Triangle |
| Rake | Positive |
| Primary Workpiece Material | Steel |
| Primary Workpiece Material Code | P |
| Secondary Workpiece Material | Stainless Steel; Cast Iron |
| Secondary Workpiece Material Code | K; M |
| Iso Code | TPKN 2204PDSR CTPP235 |
| Chip Breaker | None |
| Coating/Finish | Coated |
| Width (Decimal Inch - 4 Decimals) | 1.0000 |
| Width (Mm - 2 Decimals) | 1.00 |
| Thickness (Decimal Inch - 4 Decimals) | 0.1874 |
